| Characteristics | Conditions | Specified Values | Units |
| Geometry Characteristics |
Core Diameter | -- | 50±2.5 | [μm] |
Core Non-Circularity | -- | ≤5.0 | [%] |
Cladding Diameter | -- | 125.0±1.0 | [μm] |
Cladding Non-Circularity | -- | ≤0.6 | [%] |
Coating Diameter | -- | 245±7 | [μm] |
Coating/Cladding Concentricity Error | -- | ≤10.0 | [μm] |
Coating Non-Circularity | -- | ≤6.0 | [%] |
Core/Cladding Concentricity Error | -- | ≤1.0 | [μm] |
Delivery Length | -- | up to 17.6 | [km/reel] |
Optical Characteristics |
Attenuation | 850nm | ≤2.4 | [dB/km] |
953nm | ≤1.7 | [dB/km] |
1300nm | ≤0.6 | [dB/km] |
Overfilled Modal Bandwidth | 850nm | ≥3500 | [MHz·km] |
953nm | ≥1850 | [MHz·km] |
1300nm | ≥500 | [MHz·km] |
Effective Modal Bandwidth | 850nm | ≥4700 | [MHz·km] |
953nm | ≥2470 | [MHz·km] |
Application support distance on | -- | -- | -- |
| 1.6T-SR8.2 | 850/910nm | 100 |
|
| 800G-SR4.2 | 850/910nm | 100 | [m] |
| 400GBASE-SR4.2 | 850/910nm | 150 | [m] |
| 100Gb/s WDM1 | 850-950nm | 150 | [m] |
Numerical Aperture | -- | 0.200±0.015 | -- |
Group Refractive Index | 850nm | 1.482 | -- |
1300nm | 1.477 | -- |
Zero Dispersion Wavelength(λ0) | -- | 1297-1328 | [nm] |
Zero Dispersion Slope(S0) | -- | ≤4（-103）/（840（λ0/840)4) | [ps/(nm2·km)] |
Macrobending Loss2 | -- | @850nm | @1300nm | -- |
2 Turns @ 15 mm Radius | -- | ≤0.1 | ≤0.3 | [dB] |
2 Turns @ 7.5 mm Radius | -- | ≤0.2 | ≤0.5 | [dB] |
Backscatter Characteristics | 850nm & 1300nm |
|
Step（Mean of Bidirectional Measurement） | -- | ≤0.10 | [dB] |
Irregularities Over Fibre Length and Point Discontinuity | -- | ≤0.10 | [dB] |
Attenuation Uniformity | -- | ≤0.08 | [dB/km] |
Environmental Characteristics | 850nm & 1300nm |
|
Temperature Cycling | at -60℃ to 85℃ | ≤0.10 | [dB/km] |
Temperature-Humidity Cycling | at -10℃ to 85℃ and 4% to 98% RH | ≤0.10 | [dB/km] |
Water Immersion | at 23℃ for 30 days | ≤0.10 | [dB/km] |
Dry Heat | at 85℃ for 30 days | ≤0.10 | [dB/km] |
Damp Heat | at 85℃ and 85% RH for 30 days | ≤0.10 | [dB/km] |
Mechanical Specification |
Proof Test | -- | ≥9.0 | [N] |
-- | ≥1.0 | [%] |
-- | ≥100 | [kpsi] |
Coating Strip Force | typical average force | 1.5 | [N] |
peak force | ≥1.3, ≤8.9 | [N] |
Dynamic Stress Corrosion Susceptibility Parameter（nd, typical） | -- | 20 | -- |
Remarks:
1. Support distance with SWDM transceivers http://www.swdm.org/msa/
2. The launch condition for the macrobending loss measurement fulfils that described in IEC 61280-4-1.
Benefits and Applications
Support single-wavelength and multi-wavelength transmission system from 40 Gb/s to400 Gb/s
Data centers
Data storage networks
High-performance computing centers
Office centersLocal area networks (LAN)
Supports the use and installation of optical cables with a small bending radius
High resistance to micro-bending
Optimized performance in tight-buffer cable applications
Stable performance over a wide range of environmental conditions
