| Image Sensor | 1/3" Progressive Scan CMOS |
|
| Wide Dynamic Range | 120 dB |
|
| Day & Night | ICR Cut |
|
| Angle Adjustment | Pan: 0° to 355°, tilt: 0° to 75°, rotate: 0° to 355° |
|
| Lens Type & FOV | 2.8 mm, horizontal FOV 103°, vertical FOV 55°, diagonal FOV 122° |
| 4 mm, horizontal FOV 84°, vertical FOV 45°, diagonal FOV 100° |
| DORI | 2.8 mm: D: 67 m, O: 26 m, R: 13 m, I: 6 m |
| 4 mm: D: 80 m, O: 31 m, R: 16 m, I: 8 m |
| IR Range | Up to 30 m |
|
| Max. Resolution | 2688 × 1520 |
|
| On-Board Storage | Built-in micro SD, up to 256 GB |
|
| Perimeter Protection | Line crossing detection, intrusion detection |
| Supports human and vehicle targets classification |
| Material | Aluminium Alloy Body |
| Bubble: Plastic |
| Screw Material | SUS304 |
|
| Dimension | Ø110.8 × 84.7 mm (Ø4.4″ × 3.3″) |
|
| Weight | Approx. 530 g (1.2 lb.) |
|
| Protection | IP67 (IEC 60529-2013), IK10 (IEC 62262: 2002) |
|
