As an optical passive device, the optical fiber attenuator is used to debug optical power performance in optical communication systems, debug the calibration and correction of optical fiber instruments, and attenuate optical fiber signals. The product is made of attenuated optical fiber doped with metal ions, which can adjust the optical power to the required level. The fixed attenuator is an optical device that can reduce the energy of optical signals. It is used to attenuate the input optical power and avoid the distortion of the optical receiver caused by the excessive input optical power. Fibercloud's fixed attenuator products include six models: 0~60dB.
Characteristic
- Optional attenuation value:0~60dB
- Communication band:1260-1625nm(singlemode)/850~1300nm(Mutimode)
- Easy-to-install plug-in construction
- Diverse plug types
- Zirconia core:accurate attenuation and high return loss
- STANDARD:GR-1221-CORE, GR-1209-CORE
- RoHS compliant
- Telcordia(bellcore)GR-468-CORE reliability compliant
- Operating temperature -40 to +85ºC
- Plug and unplug>1000times
