Industrial Gigabit 1 SFP & 4-Port Ethernet Media Converter

Share to:

Industrial Gigabit 1 SFP & 4-Port Ethernet Media Converter

The switch is a compact industrial media converter featuring one SFP fiber slot and four Gigabit Ethernet ports, designed for reliable network extension in harsh environments. It delivers robust fiber-copper conversion with multimode/singlemode support for transmission distances up to 20km, while providing IEEE 802.3at/af PoE+ support on all copper ports with up to 30W per port. Housed in a fanless aluminum enclosure with IP40 protection, it operates reliably across -40°C to 85°C and supports wide-range DC power input (12-57V) via industrial terminal blocks. With DIN-rail mounting and >100,000 hours MTBF, it ensures stable connectivity for industrial automation, surveillance systems, and intelligent transportation applications.

Availability:



Inquire Add to Basket

Model:
NST-GY-GS14-SFP

Product Description

Parameter	Specification
Product Name	Industrial Gigabit 1 SFP & 4-Port Ethernet Media Converter
Model Number	NST-GY-GS14-SFP
Networking Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.3at
MTBF	>100,000 hours
Dimensions (L×W×H)	128mm × 97mm × 35mm
Power Supply	Input Voltage: DC 12-48V (Non-PoE), DC 48-57V (PoE) Per Port: Auto-sensing IEEE 802.3at/af, ≤30W Max Default Pinout: 1/2+; 3/6- Connector: 6-position 5.08mm Industrial Terminal Block
Environmental Specs	Operating Temp: -40°C to +85°C Storage Temp: -50°C to +100°C Operating/Storage Humidity: 5% to 95% (Non-condensing)
Transmission Distance	Twisted Pair: 100m (using CAT5/CAT5e cable) Multimode Fiber: 2km Singlemode Fiber: 20km
Mechanical Properties	Housing: Aluminum alloy, IP40 rated Cooling: Fanless (natural convection) Mounting: DIN-rail mountable Weight: 422g (with packaging, excluding external power adapter)
