Product Accessories
| NO. | Type | Specifications |
| 1 | Cable Ties | 10*150 mm |
| 2 | Heat shrink protective tube | 60 mm*12 pcs |
| 3 | Screw | M6*50 |
| 4 | Optical fiber protection tube | φ = 5 mm |
| 5 | Cable clamp | L = 60 mm |
| 6 | Waterproof gasket | 4 PCS |
| 7 | Manual | 1 |
| 8 | Key | 1 |
Product Parameters
| Parameter | Specification |
| Product Color | Black / White |
| Operating Temperature | -20°C to +40°C |
| Ambient Humidity | ≤95% (+40°C) |
| Atmospheric Pressure | 70 kPa to 106 kPa |
| Connector Durability | Insertion loss change ratio < 0.1 dB after 1,000 plug insertions |
| Insulation Resistance | Insulation resistance between ground device and cabinet > 1,000 MΩ/500 V (DC) |
| Withstand Voltage (V) | Withstand voltage between the ground part and cabinet > 3,000 V (DC)/5 s, no puncturing or arcing |
| Insertion Loss (dB) | ≤0.2 dB |
| Return Loss (dB) | PC ≥45 dB, UPC ≥50 dB, APC ≥60 dB |
| Standards Compliance | Other specifications compliant with the requirements of YD/T925-2009 |
Order Guide
| S/N | Type | Dimensions (HxWxD mm) | Capacity (Core) | Remarks |
| 1 | SC/LC/FC/ST | 285 X 340 X 65 | 12 | Pigtail*1m*12 |
