| Lens: | |
|---|---|
| Availability: | |
DS-2CE10DF0T-F
Hikvison
8525801302
| Image Sensor | 2 MP CMOS |
| Signal System | PAL/NTSC |
| Min. Illumination | 0.001 Lux @ (F1.0, AGC ON), 0 Lux with white light |
| Angle Adjustment | Pan: 0° to 360°, Tilt: 0° to 90°, Rotation: 0° to 360° |
| Wide Dynamic Range | Digital WDR |
| Field of Vision | 2.8 mm: 98° (H), 51° (V), 115° (D) |
| 3.6 mm: 76° (H), 41° (V), 90° (D) | |
| 6 mm: 50° (H), 27° (V), 58° (D) | |
| White Light Range | Up to 20 m |
| Max. Resolution | 1920 (H) × 1080 (V) |
| Max. Frame | TVI: 1080p@25fps/30fps |
| CVI: 1080p@25fps/30fps | |
| AHD: 1080p@25fps/30fps | |
| CVBS: PAL/NTSC | |
| Power | 12 VDC ± 25% |
| Working Temperature | -40°C to 60°C (-40°F to140°F), Humidity: 90% or less (non-condensing) |
| Material | Metal |
| Dimensions | 161.1 mm × 70 mm × 70 mm (6.34" × 2.76" × 2.76") |
| Weight | Approx. 395 g (0.87 lb) |
Application
Retail Stores: Monitors storefronts, aisles, and cashier areas with 24/7 color imaging for theft prevention and customer behavior analysis.
Residential Areas: Secures homes, driveways, and communal spaces, providing clear color visuals day and night for safety.
Small Businesses: Surveils offices, workshops, and entry points, leveraging high resolution and night vision for comprehensive security.
Product standards
Imaging: 2MP (1920×1080) resolution for clear visuals; 24/7 color imaging via F1.0 aperture; 3D DNR technology for sharp, noise - free images.
Optics: Fixed focal lenses (2.8 mm, 3.6 mm, 6 mm) to suit different viewing ranges.
Durability & Connectivity: IP67 rated for water/dust resistance; one port supports four switchable signals.
