3.0mm Sc Upc Fiber Optic Patch Cord

Characteristic

Low insertion loss & High return loss
Good exchangeability
Good Durability --High temperature stability
Superior PC/UPC/APC Polishing
Standard: IEC Grade B

Availability:



Inquire Add to Basket

Product Description

Connector Type	FC/UPC,FC/APC,SC/UPC,LC/UPC,LC/APC,ST/PC,MPO
Fiber Type	Mult Mode		Single Mode
Insertion Loss	Max.≤0.2dB		Max.≤0.3dB
Return Loss	≥36dB(no APC connector)	PC >45dB	UPC >=50dB	APC >=60dB
Repeatability	≤0.1dB
Interchangeability	≤0.2dB
Connection Durability	≥1000 times
Operating/Storage Temperature	-40~80ºC

Applications

Fiber Optic communications system
Fiber Optic access networks
CATV/CCTV
Fiber Optic data communication
Fiber Optic Test Equipment
