Function | Reference Data | Notes |
| Fibre size | UV40/125, UV105/125, UV200/220, SI 400/420, etc. | Customizable |
Connector type | SMA905, FC, etc. | Customizable |
Number of fibre cores | 3core, 7 core, 19 core, 76 core, 104 core, 208 core, etc. | Customizable |
Length | 0.3-10m | Customizable |
Fibre optic arrangement | One line, circle, square, hexagon, etc. | Customizable |
Working wavelength | 355-650nm | Customizable |
Power | 208 core, Single Core 500mW@405nm (UV105/125 fibre) 76 core, Single Core 15W@450nm (S1400/420 fibre) | Customizable |
Power consistency | ≥95%@405nm(3.5m) | Customizable |
Bundle end face cleanliness | <2 µm dirty quantity ≤ 5 (Taking UV105/125 fibre and 208cores as examples) | - |
Fibre damage threshold | 22.4J/cm2@1064nm (10.4ns, 1Hz) | - |
