| Image Sensor | 1/1.8" Progressive Scan CMOS |
|
| Max. Resolution | 2560 × 2560 |
|
| Lens Type | Fixed focal lens, 1.16 mm |
|
| Focal Length & FOV | 1.16 mm, horizontal FOV 180°, vertical FOV 180° |
|
| Supplement Light Type | IR |
|
| Supplement Light Range | Up to 15 m |
|
| Main Stream | 50 Hz: 25 fps/60 Hz: 30 fps |
| Fisheye View: 2560 × 2560, 2048 × 2048, 1280 × 1280 |
| 180 Panorama View: 2048 × 1536, 1920 × 1440 |
| 180 Dual Channel Panorama View: |
| 2048 × 768, × 1920 720 |
| Panorama View: 2048 × 1536, 1920 × 1440 |
| 4PTZ View: camera 01/camera 02/camera 03/camera 04: 1024 × 768 |
| Fisheye + 3PTZ View: camera 01: 2048 × 2048, 1024 × 1024 camera 02/camera 03/camera 04: 1024 × 768 |
| 4PTZ Fusion View: 2048 × 1536, 1600 × 1200 |
| Mount Type | Support wall/table/ceiling mounting |
|
| Wide Dynamic Range (WDR) | Digital WDR |
|
| People Counting | Counts people entering, exiting and passing by separately |
|
| Material | Metal |
|
| Dimension | Ø 140.3 mm × 59.4 mm (Ø 5.5" × 2.3") |
|
| Weight | Approx. 715 g (1.58 lb.) |
|
| Protection | IP67: IEC 60529-2013, IK10: IEC 62262:2002 |
|
