| Image Sensor | 1/2.7" Progressive Scan CMOS |
|
| Max. Resolution | 1920 × 1080 |
|
| Min. Illumination | Color: 0.005 Lux @ (F1.6, AGC ON),B/W: 0 Lux with IR |
|
| Day & Night | IR cut filter |
|
| Angle Adjustment | Pan: 0° to 355°, tilt: 0° to 75°, rotate: 0° to 355° |
|
| Lens Type | Fixed focal lens, 2.8 and 4 mm optional |
|
| Focal Length & FOV | 2.8 mm, horizontal FOV 111°, vertical FOV 59°, diagonal FOV 133° |
| 4 mm, horizontal FOV 91°, vertical FOV 46°, diagonal FOV 110° |
| Supplement Light Type | IR |
|
| Supplement Light Range | Up to 30 m |
|
| Main Stream | 50 Hz: 25 fps (1920 × 1080, 1280 × 720) |
| 60 Hz: 30 fps (1920 × 1080, 1280 × 720) |
| Wi-Fi Protocol | 802.11n: OFDM |
| 802.11b: DSSS |
| 802.11g: OFDM |
| Frequency Range | 2.412 GHz to 2.472 GHz |
|
| Wireless Range | Up to 120 m (The performance varies based on actual environment) |
|
| Antenna | 2 Antenna(s) |
|
| Built-in Microphone | Yes |
|
| Built-in Speaker | Yes |
|
| On-Board Storage | Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 256 GB |
|
| Material | Base: metal, front cover: polycarbonate, back cover: polycarbonate |
|
| Dimension | Ø 126 mm × 96.1 mm (Ø 5" × 3.8") |
|
| Weight | Approx. 590 g (1.3 lb.) |
|
| Protection | IP66: IEC 60529-2013 |
|
