| Image Sensor | 1/1.8" Progressive Scan CMOS |
| Max. Resolution | 2688 × 1520 |
| Min. Illumination | Color: 0.0005 Lux @ (F1.2, AGC ON), B/W: 0.0001 Lux @ (F1.2, AGC ON), B/W: 0 Lux with IR |
| Day & Night | Day, Night, Auto, Schedule, Alarm Trigger (with IR cut filter and blue glass module) |
| Zoom | Varifocal (multiple focal length options: 2.8 to 12 mm, 8 to 32 mm, 10 to 50 mm) |
| Focal Length | 2.8 to 12 mm；8 to 32 mm；10 to 50 mm |
| FOV | 2.8 to 12 mm: horizontal FOV 114.6° to 41.8°, vertical FOV 59.3° to 23.6°, diagonal FOV 141.3° to 48.1 °8 to 32 mm: horizontal FOV 42.5° to 15.2°, vertical FOV 23.4° to 8.7°, diagonal FOV 49.7° to 17.3° 10 to 50 mm: horizontal FOV 41.5° to 9.3°, vertical FOV 23.2° to 5.3°, diagonal FOV 49.9° to 10.7° |
| Focus | Auto, Semi - auto, Manual |
| Zoom Speed | Not specified |
| Supplement Light Range | 2.8 to 12 mm: Monitoring: 60 m 8 to 32 mm: Monitoring: 100 m 10 to 50 mm: Monitoring: 100 m |
| Main Stream | Monitoring mode: 50 Hz: up to 50 fps (2688 × 1520, 1280 × 720), up to 100 fps (1920 × 1080); 60 Hz: up to 60 fps (2688 × 1520, 1280 × 720), up to 120 fps (1920 × 1080) |
| Smart mode: 50 Hz: 25 fps; 60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720) |
| Video compression: H.265+/H.265/H.264+/H.264 |
| Wide Dynamic Range (WDR) | 150 dB |
| Dimension | With - Y: Ø140 mm × 377.4 mm (Ø5.5" × 14.9"), Without - Y: Ø144.1 mm × 374.7 mm (Ø5.7" × 14.8") |
| Weight | Approx. 2330 g (5.14 lb.) (device only)；Approx. 3575 g (7.88 lb.) (with package) |
| Material | Aluminum alloy body |
| Protection | IP67, IK10；-Y: NEMA 4X |
