Product Application
Fiber-to-the-home
Office network construction
Community/campus network construction
Radio and television transmission
Security surveillance
Product Specifications
| Parameter | Specification |
| Network Ports | 24 x Gigabit PoE Ports, 2 x Gigabit Uplink Ports |
| Interface Type | RJ45 Ethernet, Full-Duplex, Auto MDI/MDI-X |
| Network Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3x |
| Switching Method | Store-and-Forward |
| Buffer Memory | 1 Mbits |
| PoE Standard | IEEE 802.3af, IEEE 802.3at |
| PoE Pin Assignment | Pairs 1/2 & 3/6 |
| PoE Ports | Ports 1 ~ 24 |
| Max. Power per Port | 15.4 W |
| Total PoE Budget | 260 W |
| Enclosure | Metal, Fanless |
| Weight | 3250g |
| Dimensions (LWH) | 487 mm * 266 mm * 45 mm |
| Operating Temperature | 0 ℃ ~ 40 ℃ |
| Storage Temperature | -40 ℃ ~ 85 ℃ |
| Operating Humidity | 5% ~ 95% (non-condensing) |
| Power Supply | 48V DC, 1.35A |
