Product Application
Fiber-to-the-home
Office network construction
Community/campus network construction
Radio and television transmission
Security surveillance
Product Specifications
| Parameter | Specification |
| Network Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3ab |
| Ports | 8 x 10/100 Mbps Auto-Negotiation RJ45 Ports |
| Switching Method | Store-and-Forward, Wire-Speed Filtering and Forwarding |
| LED Indicators | Power, Status |
| Power Supply | External Power Adapter |
| Operating Environment | Operating Temperature: 0℃ ~ +40℃; Storage Temperature: -40℃ ~ 70℃
Operating Humidity: 10% ~ 90% RH (non-condensing);
Storage Humidity: 5% ~ 90% RH (non-condensing) |
| Product Dimensions | 120 mm * 50 mm * 21 mm |
| Product Weight | 132 g (with packaging) |
