1310nm 20MW CATV Cable TV Broadcast Equipment Fiber Optic Transmitters

The CATV direct modulation optical transmitter uses a DFB laser diode as the light source. This product adopts a pre-distortion circuit design, enabling it to achieve a high CNR (Carrier-to-Noise Ratio) while maintaining excellent Composite Triple Beat (CTB) and Composite Second Order (CSO) performance. The Stimulated Brillouin Scattering (SBS) parameter is ≤12dB.

Availability:



Inquire Add to Basket

Model:
YOT-1310/1550-20

Product Description

OPT (mW)	Output Optical Power	Displays the actual optical power of the unit.
TEMP (°C)	Laser Temperature	Displays the internal operating temperature.
TEC (A)	Cooling Current	Displays the laser’s cooling current inside the unit.
BIAS (mA)	Bias Current	Displays the laser’s bias current inside the unit.
NO: XX	Date	Displays the manufacturing date of the unit.
Optical Characteristics	Optical Power (mW)	2~30 / 2~10
	Wavelength (nm)	1310 ± 5 / 1550 ± 5
	Return Loss (dB)	>60
	Fiber Connector	FC/APC, SC/APC
Link Performance	CNR (dB)	>53
	CTB (dB)	< -65
	CSO (dB)	< -63
	SBS Suppression (dBm)	<12
RF Characteristics	Operating Bandwidth (MHz)	860 (1000MHz optional)
	RF Input Level (dBmV)	20
	Flatness (dB)	±0.75
	Return Loss (dB)	>14
Other Features	Network Management Interface	RS232
	Power Supply (V)	85~265
	Power Consumption (W)	<40
	Dimensions (mm)	483 × 385 × 44 (19'' × 15'' × 1.75'')
