YOA-1550
Parameter | Symbol | Min | Typical | Max | Unit |
Operating Wavelength | λ<sub>c</sub> | 1530 | 1550 | 1562 | nm |
Saturated Output Power<sup>1</sup> | P<sub>o</sub> | 13 | — | 24 | dBm |
Input Power | P<sub>i</sub> | -3 | — | +10 | dBm |
Gain | G | — | 20 | — | dB |
Noise Figure<sup>2</sup> | NF | — | 4.5 | — | dB |
Output Power Stability | ΔP<sub>o</sub> | — | ±0.05 | ±0.1 | dB |
Input Isolation | ISO<sub>i</sub> | 30 | — | — | dB |
Output Isolation | ISO<sub>o</sub> | 30 | — | — | dB |
Input Pump Leakage | PumpL<sub>in</sub> | — | — | -35 | dBm |
Output Pump Leakage | PumpL<sub>out</sub> | — | — | -45 | dBm |
Return Loss | RL | — | — | -45 | dB |
Polarization-Dependent Gain | PDG | — | — | 0.3 | dB |
Polarization Mode Dispersion | PMD | — | — | 0.5 | ps |
